Zapco Z-1KD II Mono 1000-Watt Class D Bass Amplifier

Product Information

Model: Z-1KDII | UPC: 8033373003080

The Z-II Series. Competition Sound Quality Amplifiers.

The Z-II Series amplifiers are meticulously engineered to offer everyday usability while delivering competition-level sound quality. They incorporate advanced circuit designs and top-of-the-line internal components to ensure the accurate reproduction of sound. Additionally, user-friendly features like adjustable crossovers and gain controls make operating the Z-II series a breeze for all users. Available in multi-channel class AB (full range) and mono class D (bass) configurations, the Zapco Z-II series of amplifiers provide the versatility and performance required to meet the demands of any audio system.

Features

• 1000-Watt Mono Class D linkable, bass amplifier
• Stable into 1 Ohm (2 Ohm w/2 amps Linked/Strapped)
• Selectable left and right operation for Linked (strapped) amplifier operation
• PWM MOSFET power supply means increased storage and less resistance to deliver higher efficiency and current handling
• 24 dB Variable low pass (LPF) crossover
• 12 dB Variable bass boost equalization to dial in low frequencies
• 0 – 180-degree variable phase shift helps blend the lows in with the rest of the system
• 24 dB Variable subsonic filter provides a steeper slope allowing for a more complete attenuation of subsonic frequencies
• Panel mount RCA connectors allow for a clean look and secure connection
• Compatible with Z-BR II bass remote control (sold separately)

Specifications

• Power @ 4Ω: 450 watts
• Power @ 2Ω: 700 watts
• Power @ 1Ω: 1050 watts
• Linked @ 2Ω: 1800 Watts
• THD @ Rated Power < 0.05%
• Signal to Noise Ratio >90dB
• Damping factor: >350
• Efficiency: 86%
• Input Sensitivity .2v to 8v
• Dimensions (W x H x L): 7.48″ x 2.44″ x 10.82″

What’s In The Box

• Z-1KD II Mono 1000-Watt Class D Bass Amplifier
• Installation Accessories
• Owner’s Manual
