Zapco Z-150.6 II 6-Channel 1650-Watt Class AB Amplifier

Product Information

Model: Z-150.6 II | UPC: 8033373003035

The Z-II Series. Class AB Competition Sound Quality Amplifiers.

The Z-II Series amplifiers are meticulously engineered to offer everyday usability while delivering competition-level sound quality. They incorporate advanced circuit designs and top-of-the-line internal components to ensure the accurate reproduction of sound. Additionally, user-friendly features like adjustable crossovers and gain controls make operating the Z-II series a breeze for all users. Available in multi-channel class AB (full range) and mono class D (bass) configurations, the Zapco Z-II series of amplifiers provide the versatility and performance required to meet the demands of any audio system.

Features

• 6-Channel, Full Range Class-AB Sound Quality Amplifier
• Stable into 4 ohms bridged or 2 ohms stereo load
• PWM MOSFET power supply for higher efficiency and current handling
• High-end Op-amps and Capacitors produce a better signal-to-noise ratio with lower floor noise
• Variable FULL/LP/HP Electronic Crossover allows for flexible amplifier configuration
• 0-12dB variable bass boost to dial in low frequencies
• 2-CH, 4-CH or 6CH of input making it possible to drive all the channels from a single 2-CH (head unit) stereo output
• Panel mount RCA connectors allow for a clean look and secure connection
• Compatible with Z-BR II bass remote control (sold separately)

Specifications

• Power @ 4Ω: 6 x 165 watts
• Power @ 2Ω: 6 x 275 watts
• Power @ 4Ω Bridged: 3 x 550 watts
• THD @ Rated Power: < 0.05%
• Signal to Noise Ratio: >100dB
• Frequency Response: 10Hz to 30,000Hz ±1dB
• Input Sensitivity: .5v to 8v
• Dimensions: 7.48″ x 2.44″ x 24.17″

What’s In The Box

• Z-150.6 II 6-Channel 1650-Watt Class AB Amplifier
• Installation Accessories
• Owner’s Manual
