Summit Appliance offers a quality selection of 20″ wide built-in undercounter all-freezers designed for installation under lower ADA compliant counters, with advanced features for user convenience. 32″ high to fit under lower counters complying with ADA guidelines for accessibility. The fully finished stainless steel cabinet allows freestanding use, while the front-breathing system means this unit can be built-in with minimum clearance. The stainless steel, user-reversible door is 3″ thick for efficient insulation, with a curved towel bar handle included for added convenience. This unit comes with a right angle cord to allow for easier placement without added depth. A digital… Summit Appliance offers a quality selection of 20″ wide built-in undercounter all-freezers designed for installation under lower ADA compliant counters, with advanced features for user convenience. 32″ high to fit under lower counters complying with ADA guidelines for accessibility. The fully finished stainless steel cabinet allows freestanding use, while the front-breathing system means this unit can be built-in with minimum clearance. The stainless steel, user-reversible door is 3″ thick for efficient insulation, with a curved towel bar handle included for added convenience. This unit comes with a right angle cord to allow for easier placement without added depth. A digital thermostat, located in the kickplate, makes for easy temperature management with a readout in Fahrenheit or Celsius. Read more Specifications
| Overview | |
| Height of Cabinet | 31.75″ (81 cm) |
| Height to Hinge Cap | 32.0″ (81 cm) |
| Width | 19.75″ (50 cm) |
| Width with Door Open | 20.25″ (51 cm) |
| Depth | 23.0″ (58 cm) |
| Depth with Handle | 24.38″ (62 cm) |
| Depth with door at 90° | 40.25″ (102 cm) |
| Capacity | 3.53 cu.ft. (100 L) |
| Defrost Type | Automatic |
| Door | Panel-Ready |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Energy Usage/Year | 251.0kWh/year |
| Amps | 1.1 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 75.0 lbs. (34 kg) |
| Shipping Weight | 80.0 lbs. (36 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101076522 |
| Refrigerator Features | |
| Door Swing | RHD |
| Reversible | No |
| Crisper Qty | 1 |
| Crisper Finish | Transparent |
| Crisper Cover | Glass |
| Shelf Type | Glass |
| Shelf Qty | 3 |
| Full Door Shelf Qty | 3 |
| Thermostat Type | Digital |
| Fan Type | Interior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 0.99oz. |
| High Side PSI | 180.0 |
| Low Side PSI | 80.0 |
| Level Legs Qty | 2 |
| Wheel Qty | 2 |
| Interior Light | Yes |
| Temperature Range | 35 to 46°F |
| Dimensions | |
| Interior Height | 23.5″ (60 cm) |
| Interior Width | 16.25″ (41 cm) |
| Interior Depth | 17.0″ (43 cm) |
| Compressor Step Height | 6.25″ (16 cm) |
| Compressor Step Width | 16.25″ (41 cm) |
| Compressor Step Depth | 6.0″ (15 cm) |
| Exterior | |
| TT – Installed thermometer | SCD – Self-closing door |
| PH – Probe Hole | LHD – Left hand door swing |
| HG – Hospital grade cord | Alarm |
| DL2B – Factory installed NIST calibrated digital data logger (DDL) | – |
| Overview | |
| Height of Cabinet | 31.75″ (81 cm) |
| Height to Hinge Cap | 32.0″ (81 cm) |
| Width | 19.75″ (50 cm) |
| Width with Door Open | 20.25″ (51 cm) |
| Depth | 23.0″ (58 cm) |
| Depth with Handle | 24.38″ (62 cm) |
| Depth with door at 90° | 40.25″ (102 cm) |
| Capacity | 3.53 cu.ft. (100 L) |
| Defrost Type | Automatic |
| Door | Panel-Ready |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Energy Usage/Year | 251.0kWh/year |
| Amps | 1.1 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 75.0 lbs. (34 kg) |
| Shipping Weight | 80.0 lbs. (36 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101076522 |
| Refrigerator Features | |
| Door Swing | RHD |
| Reversible | No |
| Crisper Qty | 1 |
| Crisper Finish | Transparent |
| Crisper Cover | Glass |
| Shelf Type | Glass |
| Shelf Qty | 3 |
| Full Door Shelf Qty | 3 |
| Thermostat Type | Digital |
| Fan Type | Interior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 0.99oz. |
| High Side PSI | 180.0 |
| Low Side PSI | 80.0 |
| Level Legs Qty | 2 |
| Wheel Qty | 2 |
| Interior Light | Yes |
| Temperature Range | 35 to 46°F |
| Dimensions | |
| Interior Height | 23.5″ (60 cm) |
| Interior Width | 16.25″ (41 cm) |
| Interior Depth | 17.0″ (43 cm) |
| Compressor Step Height | 6.25″ (16 cm) |
| Compressor Step Width | 16.25″ (41 cm) |
| Compressor Step Depth | 6.0″ (15 cm) |
| Exterior | |
| TT – Installed thermometer | SCD – Self-closing door |
| PH – Probe Hole | LHD – Left hand door swing |
| HG – Hospital grade cord | Alarm |
| DL2B – Factory installed NIST calibrated digital data logger (DDL) | – |
Manuals & Guides
- Brochure
- Use & Care
- Use & Care
Features
- ADA compliant design : 32″ height allows easy installation under lower ADA compliant counters
- Open door alarm : Audible alarm will sound if the door is left ajar for over a minute
- Built-in capable : Front-breathing design lets you make the best use of space by installing your appliance under the counter
- Panel-ready door : Integrated stainless steel door frame accepts full overlay panels, allowing you to customize the refrigerator door or blend it into your cabinetry design; panel size: 19 13/16″ W x 27 1/8″ H; customers provide their own handles
- Adjustable thermostat : Digital thermostat offers easy temperature management with a readout in Fahrenheit or Celsius
- Door shelves : Three removable door racks for additional storage of larger items
- Adjustable glass shelves : Three adjustable spill-proof shelves for optimal storage in 3.53 cu. ft. interior
- Fruit and vegetable crisper : Get the longest life and best taste out of produce by storing greens in a convenient slide drawer
- 3″ thick door : Improved insulation for an efficient performance; NOTE: due to the oversized design, the door does open in its own radius. If installing this refrigerator against a wall, please see our drawings to ensure adequate space
- Temperature alarms : User-set high/low temperature alarms provide added security if temperature goes beyond setpoint
