Simaudio Moon 680D Streaming DAC Store Demo 5 Year Warranty
STORE DEMO – 5 YEAR WARRANTY – FINAL SALE
MiND 2 streaming module
MiND 2 (MOON intelligent Network Device) is a fabulous way of streaming and listening to your music. The 680D is designed to deliver an outstanding high-resolution streaming experience through music services such as Tidal Masters, Qobuz Sublime+ and Deezer Hi-Fi. The DAC architecture supports PCM (up to 32-bit/384kHz), DSD (up to DSD256) and is MQA certified.
Roon Ready & full MQA decoding
The 680D is Roon Ready and allows the playback of all the most common file formats, including DSD, and MQA file formats via all inputs.
A Team Player
The 680D is the prodigal little brother of the 780D, and it is the best buddy of the 600i v2. Together, they form a great pair to recreate the best sound for your favourite music.
Design features
Roon Ready device
DSD and MQA decoding from all digital inputs
Tidal Masters, Deezer Hi-Fi and Qobuz Sublime+ Music Services
Multi-room synchronized playback
9 digital inputs : USB, AES/EBU, SPDIF, Optical, Ethernet, Wi-Fi and aptXTM audio for Bluetooth
Power supply using new MOON Hybrid Power (MHP) for exceptionally stable, ultra low noise DC output
12 stages of DC voltage regulation which includes 2 stages of M-LoVo (MOON Low Voltage Regulation) and 4 stages of i2DCf (Independant Inductive DC Filtering)
On-board programmable software for customization of the end-user interface
Specs
Specifications
Frequency response (full range)
2Hz – 100kHz +0/-3dB
THD @ 1kHz, 0dBFS (A-weighted)
0.0005 %
Intermodulation distortion
0.0003 %
Dynamic Range
123 dB
Signal-to-noise Ratio
123 dB @ full output
Channel Separation
120 dB
Intrinsic Jitter
1 pico seconds RMS
Analog Output @ 0dBFS
2.0 V
Analog output impedance
100
PCM Bit-depth range
16 – 32 bits
PCM sampling frequency rates
44.1 – 384 kHz
DSD sample rates
DSD64, DSD128 & DSD256
Shipping weight
38 lb / 18 kg
Dimensions (width x height x depth)
18.75 x 4.0 x 16.8 in
47.6 x 10.2 x 42.7 cm
