Shure MVX2U Digital Audio Interface XLR to USB-C Adapter with Headphone Output

Product Information

Model: MVX2U | UPC: 042406767767

The MVX2U Digital Audio Interface is a powerful, single-channel XLR-to-USB adapter that allows you to connect any XLR microphone to a computer for effortless recording and streaming. With configurable DSP features and full access to ShurePlus MOTIV Desktop App, the compact interface is future-proofed via online firmware updates. Providing up to 60dB of clean gain, the XLR-to-USB adapter has enough power to bring your favorite dynamic microphone, such as the legendary SM7B, to life. It also offers up to 48v of phantom power for connecting a condenser microphone to your computer. Portable, sleek and rugged, the MVX2U can be plugged straight onto an XLR microphone or used in-line with an XLR cable, depending on your setup.

Features

• Auto Level Mode
• Configurable onboard DSP via the ShurePlus MOTIV Desktop App
• A built-in 3.5mm headphone jack with zero-latency monitoring
• 48v of phantom power for condenser microphones
• Clean gain of up to 60dB that is sufficient to amplify signals for dynamic microphones
• Portable form factor with a sleek yet robust build
• Compatible with both Mac and Windows
• 1m USB-C to USB-C cable included

ShurePlus MOTIV Desktop App

This free app unlocks the following features for any XLR microphone using the MVX2U:

Auto Level Mode

• Set your distance Near or Far from the microphone, and let MVX2U auto matically adjust your gain level in real-time with intelligent onboard DSP for consistent audio output.
• Customize your vocal tone by selecting between a Dark, Natural or Bright
  sound signature.

Manual Mode

• Get full control of your mic output with configurable DSP features, such as Gain, Limiter, Compressor, EQ and more.
• Save your own presets for quick future access.

Monitor Mix

• Set your preferred blend of monitoring and playback via the built-in headphone jack.

Firmware Updates

• Firmware update ensure your interface will always have the latest features from Shure.

Specifications

• General
  • Input: XLR
  • Input impedance: 5.8kΩ
  • Bit Depth: 16-bit/24-bit
  • Sampling Rate: 48kHz
  • Frequency Response: 20Hz to 20,000Hz
  • Adjustable Gain Range: 0 to +60dB
  • Maximum Input Level: 7dBV
  • Power Requirements: Powered through USB-C
  • Phantom Power: +48VDC
  • Digital Noise Floor (20 Hz to 20 kHz, A-weighted): -117dBFS
  • LED Indicator (Tricolor)
    • Green = Ready
    • Amber = Error
    • Red = Mute
  • Housing: All Metal
  • Net Weight: 100 g (3.5 Oz.)
  • Dimension (W x H x D): 5.51” x 1.73” x 6.22”
  • Headphone Output: 3.5 mm (1/8 inch) 20 mW @ 32Ω
  • Cable: 1M USB-C to USB-C cable
• System Requirements
  • USB: USB 2.0
  • RAM: 64MB RAM (minimum)
  • Minimum 500 MB of hard disk space
  • Operating System
  • MacOS 10.15 to 13 (64 bit)
  • Windows 10 (64 bit)

What’s In The Box

• MVX2U Digital Audio Interface XLR to USB-C Adapter with Headphone Output
• 1m USB-C to USB-C Cable
• Manual
