Sanus VIWLF128 Premium Large In-Wall Full Motion TV Mount for 42″-85″ TVs

Product Information

Model: VIWLF128-B2 | UPC: 793795538741

The VIWLF128-B2 Large In-Wall Full Motion mount provides the optimal viewing experience with space for AV components built in. This full motion mount extends 28″ with up to 67° of swivel left and right and sits just .5″ from the wall when recessed. Mount arms fold into a 20″ enclosure that can double as AV storage for streaming devices, switches and more. With knockouts to add power (not included) and cable management, The VIWLF128 offers a stylish industrial design that achieves the ultimate all-in-one AV experience.

Features

• For TVs 42″-85″
• fits between two 16″ on center studs
• Virtual Axis™ finger-tip tilt to reduce glare
• Swivels up to 67° left and right (with 65” TV)
• 28″ of extension and sits just 0.5” from the wall when recessed
• Six components  attachment slots with included Velcro
• Click-lock mechanism

Specifications

• Model Code: VIWLF128
• UPC Code: 793795538741
• Product Width: 24.90″
• Product Height: 20.80″
• Product Depth: 28.00″
• TV Size Range: 42″ – 85″
• Maximum TV Weight: 135lbs
• Universal Mounting: Yes (100 x 100 through 600 x 400)
• Tilt: 4° / -10° (with 65” TV)
• Swivel: 67° / -67° (with 65” TV)
• Required Tools
  • 1/4″ Drill Bit
  • 1/2″ Socket Wrench
  • Allen Wrench
  • Drywall Saw
  • Electric Drill
  • Level
  • Pencil
  • Stud Finder
  • Tape Measure

What’s In The Box

• VIWLF128 Premium Large In-Wall Full Motion TV Mount for 42″-85″ TVs
• Installation Hardware
• Manual
