Rotel T11 FM/DAB+ Tuner (Black)

Product Information

Model: T11B | UPC: 672563245114

Rotel has been producing quality tuners since the 1960s. One of the latest additions to this long-established line-up is the T11 FM/DAB+ tuner. It provides a wealth of listening options with easy access to classic analogue FM stations as well as newer DAB+ (Digital Audio Broadcasting) services. Like the T14, T11 features the ability to easily store and recall up to 30 presets each for FM or DAB+ stations. A further useful feature common to all 14 Series products is the ability to dim the display panel and power LED to provide a comfortable visual reference in all lighting environments.

Features

• DAB+ Tuning
• Radio Data System (FM Broadcasts)
• Save Up to 30 Presets
• Remote Included

Specifications

• FM Tuner
  • Usable Sensitivity: 22.2 dBf
  • 50dB Quieting Sensitivity: 27.2 dBf (mono)
  • Signal to Noise Ratio
  • Mono: 63 dBf (at 65 dBf)
  • Stereo: 60 dBf (at 65 dBf)
  • Harmonic Distortion
  • Mono: 0.2% (at 65 dBf)
  • Stereo: 0.3% (at 65 dBf)
  • Frequency Response: 10Hz – 15kHz, ± 3dB
  • Stereo Separation (100Hz/1kHz): 40 dB / 37 dB
  • Analog Output: 1.0 V
  • Antenna Input: 75 Ohms F connector
• DAB Tuner
  • Sensitivity: – 80 dBm
  • Tuning Range: Band III (174 – 240MHz)
  • Audio Data Rate: 224kbps (Max)
  • Frequency Response: 20 – 20kHz, +/- 1.0 dB
  • Analog Output: 2.1V at 0 dBFS
  • Antenna Input: 75 Ohms F connector
• General
  • Power Requirements (AC): 120V, 60Hz
  • Power Consumption: 10 watts
  • Standby Power Consumption: < 0.5 watts
  • Dimensions (W x H x D): 17″ x 2-7/8″ x 13″
  • Front Panel Height: 2-3/8″
  • Weight (net): 9.5 lbs.
