Parasound ZoneMaster 4 DAX Four Zone 192kHz 24bit DAC and Crossover B-Stock No Warranty

Parasound ZoneMaster 4 DAX Four Zone 192kHz 24bit DAC and Crossover B-Stock No Warranty

Four Independent DACs in a single chassis

192kHz/24bit ESS Sabre DAC ICs

Level controls for all channels

Hyperstream jitter eliminator

3 Volt high gain outputs

Optical and coaxial digital inputs

Indicators for digital input signal lock and analog audio output

12V trigger output for each zone with turn off delay

All crossovers are 80Hz and 18dB /octave

Full range stereo outputs

Full range mono outputs

High pass stereo outputs

High pass mono outputs

Low pass mono subwoofer outputs

Specs

Frequency Response (analog output)
10 Hz – 20 kHz, +0/-0.5 dB

Total Harmonic Distortion
0.009%

Interchannel Crosstalk
84 dB at 20 kHz

Audio Output Level
3.0 Volts RMS

S/N Ratio
>100 dB, IHF A-weighted
Supported Sampling Rates (digital input)
Up to 192 kHz / 24-bit PCM

Digital to Analog Converter
ESS Sabre ES9023

Crossover Frequency (high and low pass)
80Hz and 18dB /octave

DC Trigger Output
12 Vdc, 50 mA per zone

AC Power Requirement:
10 Watts maximum
90-250 VAC 50/60 Hz

Dimensions:
Width: 17.25″ (437 mm)
Depth: 14.25″ (362 mm)
Depth: 16″ (369 mm) with cables connected
Height, with feet: 2.5″ (105 mm)
Height, without feet: 1.75″ (44.5 mm), 1U

Weight:
Net: 11 lbs (5 kg)
Shipping: 17 lbs (7.7 kg)
