Lexmark CS331DW Color Laser Printer

Product Details

Main Features

• Color printouts
• Double sided printing
• 26 pages per minute print speed
• Standard Wi-Fi connectivity
• USB port
• Compact size
• Light weight

Specifications

General Specifications

Part #

Print Technology

Workgroup Size

Display

Media Sizes Supported

Included Paper Handling

Standard Ports

Size (in. – H x W x D)

Weight (lb.)

Packaged Size (in. – H x W x D)

Packaged Weight (lb.)

40N9020

Color Laser

Small-Medium Workgroup

2-line All Points Addressable (APA) monochrome LCD display

A6, Oficio, 7 3/4 Envelope, 9 Envelope, JIS-B5, A4, Legal, A5, Hagaki Card, Letter, B5 Envelope, Statement, C5 Envelope, Executive, Universal, DL Envelope, Folio, 10 Envelope

100-Sheet Output Bin, Integrated Duplex, Single-Sheet Manual Feed, 250-Sheet Input

802.11b/g/n Wireless, USB 2.0 Specification Hi-Speed Certified (Type B), Ethernet 10/100/1000 BaseTX (RJ-45)

9.6 x 16.2 x 15.5 in.

35.5 lb.

20.4 x 13.1 x 21.9 in.

42 lb.

Printing

Print Speed

Print Speed Duplex

Time to First Page

Print Resolution

Duplex

Printable Area

Up to: Black: 26 ppm1 (Letter) Color: 26 ppm1 (Letter)

Up to: Black: 13 spm1 (Letter) Color: 13 spm1 (Letter)

As fast as: Black: 10.9 seconds Color: 10.9 seconds

Black: 4800 CQ (2400 x 600 dpi) Color: 4800 CQ (2400 x 600 dpi)

2-sided: Integrated Duplex

0.17 inches of the top, bottom, right and left edges (within)

Paper Handling

Media Types Supported

Finishing Option

Number of Paper Inputs

Paper Input Capacity

Paper Output Capacity

Paper Weight Range Supported

Recommended Monthly Page Volume

Maximum Monthly Duty Cycle

Paper Labels, Card Stock, Plain Paper, Envelopes, Glossy Paper, Refer to the Paper & Specialty Media Guide

No

Standard: 2 Maximum: 2

Standard: 250+1 pages 20 lb or 75 gsm bond Maximum: 250+1 pages 20 lb or 75 gsm bond 250+1 pages 20 lb or 75 gsm bond

Up to: Standard: 100 pages 20 lb or 75 gsm bond Maximum: 100 pages 20 lb or 75 gsm bond

lb.: 16 -47 lb. (Standard Tray)

600 – 2500 pages2

Up to: 50000 pages per month3



Hardware

Processor Speed

Memory

Hard Disk

Printer Languages

Fonts and Symbol Sets

Touch Screen Display

Dual Core, 1.0 GHz

Standard: 512 MB Maximum: 512 MB

Not Available

Standard: PCL 5c Emulation, PCL 5, PCL 5e Emulation, PCLm, PCL 6 Emulation, PostScript 3 Emulation, Direct Image

2 PCL bitmap fonts, OCR-A, OCR-B scalable PCL 5e fonts, For more information, refer to the Technical Reference., 91 scalable PostScript fonts, 3 of 9 scalable PCL 5e fonts in Narrow, Regular and Wide, 89 scalable PCL fonts

No

Connectivity

Direct USB

Ethernet Network

Wireless

Network Protocol Support

Network Printing Methods

Network Management Protocols

Network Security

No

Yes

Yes

TCP/IP IPv6, TCP/IP IPv4, TCP, UDP

LPR/LPD, Microsoft Web Services WSD, FTP, TFTP, Enhanced IP (Port 9400), IPP 1.0, 1.1, 2.0 (Internet Printing Protocol)

DHCP5, APIPA (AutoIP)5, BOOTP, RARP5, mDNS5, IGMP5, WINS5, DDNS5, SNMPv35, SNMPv1, SNMPv2c5, NTP5, ICMP5, HTTP5, DNS5, ARP5, HTTPs (SSL5/TLS)5, Finger5

IPSec, SNMPv3

Supported Operating Systems

Microsoft Windows Operating Systems Supported

Apple Operating Systems Supported

Android Operating System Support

Linux Operating Systems Supported

Citrix MetaFrame

Novell Operating Systems Supported

Windows 10, Windows 8, Windows 8 x64, Windows 7 x64, Windows Server 2016, Windows 7

Support is provided through AirPrint and AirScan only

Support is provided through Mopria® Print Service and Mopria Scan.

openSUSE Linux 15, Debian 9.4, 9.5, 9.6, Debian GNU/Linux 8.11, Ubuntu 16.04, 18.04 LTS, openSUSE Linux 42.3, Red Hat Enterprise Linux WS 6.10, 7.5, 7.6, Fedora 27, 28, 29, SUSE Linux Enterprise Server 10, 11, 12

Microsoft Windows Server 2003 and 2003 X64 Edition with Citrix XenApp 5.0, Microsoft Windows Server 2003 x64 running Terminal Services with Citrix Presentation Server 4.0 x64, 4.5 x64, Microsoft Windows 2000 Server running Terminal Services with Citrix Presentation Server 3.0, 4.0, Microsoft Windows Server 2003 running Terminal Services with Citrix Presentation Server 4.0, 4.5

Novell Open Enterprise Server 2 (SP3) on SuSE Linux Enterprise Server 10 SP4 (x86 and x64) 3, Novell Open Enterprise Server 11 (SP3) on SuSE Linux Enterprise Server 11 SP4 (x86 and x64), Novell NetWare 6.5 Open Enterprise Server, Novell Open Enterprise Server 15 (SP1) on SuSE Linux Enterprise Server 11 SP4 (x86 and x64), Novell Open Enterprise Server 11 (SP3) on SuSE Linux Enterprise Server 12 SP1 (x86 and x64)

Electrical & Operation

ENERGY STAR

ENERGY STAR Typical Electricity Consumption

Noise Level

Duplex Print Noise Level

Average Power

Specified Operating Environment

Product Certifications

UNSPSC Code

Harmonized Tariff Code

Country of Origin

Yes

TEC: 0.31 kilowatt-hours per week

Operating: 14 dBA (Idle) 52 dBA (Print)

Operating: 51 dBA

NA watts (Hibernate Mode) 0.84 watts (Sleep Mode) 15 watts (Ready Mode) 395 watts (Printing)

Humidity: 8 to 80% Relative Humidity Altitude: 0 – 3048 Meters (10,000 Feet) Temperature: 10 to 32°C (50 to 90°F)

ENERGY STAR, Blue Angel DE-UZ 219, ICES-003 Class B, US FDA/CDRH, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62311, EN 55022(Class B), EN 55024, EN 61000, EN 61000, UL), EFTA (CE), KCC, CCC, CECP, CEL, RCM DoC, UL-AR, KC mark, UL GS mark, UCRF, BSMI EMC Class B, Wi-Fi CERTIFIED, China Green Product (CGP), Mopria Certified

43212105

8443.32.1010

China (PRC)

  Download Manufacturer Specifications
