Kimber Kable 8TC Ascent Series Speaker Cable with SBAN Connector
HIGH CURRENT BRAIDED LOUDSPEAKER CABLE
16 strands of 19.5 AWG OFE (oxygen free electrolytic) copper with industry leading conductivity. (102% IACS).
Aggregate combination of 8, 19.5AWG strands=9AWG per +/- leg.
Teflon insulation. White/Clear
LOW series induction design: 0.09 uH / meter
Features
Low loss fluorocarbon dielectric
8 wire counter opposed helix
VariStrand copper conductors
Nitrogen assisted hand soldered termination
Specs
0″>
Connector Options
Bare Wire SPADE (1/4″) SBAN Postmaster 33 (5/16″) WBT 0681 CU (5/16″) WBT 0661 CU (1/4″) WBT 0610 CU
Electrical Specifications
Standard
(Cp) parallel capacitance: 136 pF / meter(Ls) series inductance: 0.225 uH / meter(Rdc) dc loop resistance: 0.016 Ohm / meter
