Integra CDC-3.4 Premium 6-Disc Carousel Changer

Product Information

Model: CDC-3.4 | UPC: 751398005442

The best parts, technology, and engineering come together to bring you an unparalleled music listening experience.

Original and Exclusive 6-Disc CD Carousel

Integra was the first company to offer an exclusive 6-disc carousel in a CD changer. The tradition continues with the newly redesigned CDC-3.4. It features smooth & quiet mechanical operation, plus a soft blue light which illuminates the disc tray for better visibility. You can also load up to 5 discs while one is still playing for extended listening times without interruption.

Vector Linear Shaping Circuitry

Conventional analog filters reduce digital noise at the D/A conversion stage, and then the VLSC uses a ‘Vector Generator’ to output a smooth and noiseless analog signal. This results in a dramatically improved sound quality for all types of music signals.

Specifications

Audio Performance

• Disc compatibility: CD, CD-R, CD-RW
• Signal readout system: Optical non-contact
• Error correction system: Cross-interleave Reed-Solomon Code (CIRC)
• Multi-bit digital to analog converter: Wolfson 192kHz/24-bit (x2)
• Digital filter: 128 times oversampling
• Frequency response: 5Hz – 20kHz
• THD (Total Harmonic Distortion): 0.005% (at 1kHz)
• Audio dynamic range: 96dB
• S/N ratio: 98dB
• Channel separation: 92dB (at 1kHz)

Audio Outputs

• Audio output (Digital/Optical): -22.5dBm
• Audio output/impedance (Digital/Coaxial): 0.5V (p-p)/75Ω
• Audio output/impedance (Analog): 2.0V (rms)/470Ω

General

• Power supply rating: AC 120V 60Hz
• Power consumption: 10W
• Standby power consumption: 4W
• Dimensions (W x H x D): 17 1/8″ x 5 3/16″ x 17 3/16″
• Weight: 15.2 lbs.

What’s In The Box

• CDC-3.4 Premium 6-Disc Carousel Changer
• RCA/phono audio connecting cable
• RI cable
• Remote control with two batteries
• Power cord
