Ikeda 9TS Moving Coil Phono Cartridge

Ikeda 9TS Moving Coil Phono Cartridge

Tonally it has the same musicality as the other MC cartridges in the 9 family. No compromises are made also during processing.
The 9TS 0.35mV is about twice as high output voltage compared to the 9TT so that it can be

Specs

Output Voltage:
0.35mVrms (1kHz 35.4mm/sec. at 45 peak)
Coil Impedance:
6.0 Ohms (1kHz)
Appropriate Stylus Force:
2.0 Grams 0.2 Grams
Frequency Response:
10Hz – 45kHz
Channel Separation:
Over 27dB (1kHz)
Channel Balance:
Within 1.0dB (1kHz)
Stylus Chip:
Oval-shaped solid diamond
Cantilever:
Double layered duralumin pipe
Weight:
10 Grams
Compliance:
7 x 10-6cm/dyne
Connecting Terminals:
Left Channel, White (hot), Blue (ground)
Right Channel, Red (hot), Green (ground)
