Audison APBX 8 R Prima 8 Inch Single 4 Ohm Ported Subwoofer Enclosure System

Audison APBX 8 R Prima 8 Inch Single 4 Ohm Ported Subwoofer Enclosure System

The APBX 8 R loaded enclosure was developed with reflex loading, with tuning designed to concentrate SPL in the lowest frequency range. The aim was to exploit the natural boost in output found in most cars below 60 Hz known as cabin gain . The 8-inch single 4 voice-coil subwoofer has a powerful motor that maximizes efficiency in combination with the AP8.9 bit amplifier. The low-resonant frequency of the subwoofer, matched to the reflex enclosure keeps excursion low within the entire audio spectrum, allowing also the use with a pair of AP4.9 bit / AP4 D bridged channels, capable of delivering 260 W rms.

Specs

CompREFLEX SUB BOX
Size200 mm (8 )
Power Handling250 W Continuous Power
500 W Peak Power
Impedance4
Sub box size mm (in.)473 (18.62) x 334 (13.15) x 109 (4.29)
MagnetHigh density flux ferrite
ConeCotton-Fibre pressed paper
Weight of one component kg (lb)6,64 (14.64)
