AudioControl ACX-300.4 All-Weather 4-Channel Amplifier

Product Information

Model: 8510340 | UPC: 851523007836

All-Weather Four-Channel Amplifier

AudioControl’s ACX-300.4 all-weather amplifier delivers honest power levels to the sound system in your boat, ATV, motorcycle, and more. for a two or four-channel system, the ACX-300.4 will ensure your open-air speakers deliver plenty of punch and clarity, all day long. Installer-friendly, heavy-gauge quick-connect wiring makes installation quick and painless, making the ACX-300.4 all-weather amplifier the perfect solution for your next adventure.

Features:

• 4 x 75 watts @ 2 ohms
• 4 x 50 watts @ 4 ohms
• 150 watts @ 4 ohms bridged
• IPX6 Rated
• GTO™ Signal Sense
• High and low input modes
• 4 and 2 channel input modes
• Linkwitz-Riley Crossover
• Bulletproof 5-year warranty (when installed by an authorized AudioControl dealer)

Specifications

• Inputs
  • Preamp/Speaker Level Inputs: 4
  • Input Voltage Low: 500 mV – 6 Vrms
  • Input Voltage Range High: 1 Vrms – 12 Vrms
•  Outputs
  • Rated Continuous (RMS) Power at 14.4V:
    • 4Ω – 50 W x 4 RMS
    • 2Ω – 75 W x 4 RMS
    • Bridged 4Ω – 150 W RMS
•  Performance
  • Frequency Response: 26 Hz – 22 kHz
  • Signal to Noise: 106 dBA, Ref 50 W @ 4 Ohm
  • THD+N: < 0.2%
  • Crossover: 12 dB/octave Linkwitz-Riley, 80 Hz, 120 Hz, Bypass
  • IP Rating: IPX6
• Weight & Dimensions
  • Dimensions (W x H x D): 9.0″ x 2.25″ x 3.875″
  • Weight: 7.2 lbs. (3.3 kg)

What’s In The Box

• ACX-300.4 All-Weather 4-Channel Amplifier
• 7″ Power & Ground Harness
• (2) 7″ Speaker Output Harness
• Power & Ground Connector
• (2) Crimp-On Terminals
• Installation Hardware
• Manual
• 5 Year Warranty
