Audio-Technica AT-VM95SH Dual Moving Magnet Cartridge

Product Information

Model: AT-VM95SH | UPC: 4961310145989

This VM95 Series cartridge with 2.7 x 0.26 mil Shibata stylus fits half-inch mount turntables. The cartridge offers excellent channel separation and low distortion for outstanding tonal quality. The durable, low-resonance housing includes threaded inserts that enable the cartridge to be mounted to the headshell with just two screws – no nuts required. And since all VM95 Series share the same body, the stylus can be replaced with any of the six interchangeable AT-VMN95 replacement styli.

Features

• VM95 Series dual magnet cartridge with 2.7 x 0.26 mil Shibata stylus
• Aluminum cantilever
• Durable low-resonance polymer housing
• Threaded inserts in cartridge body enable cartridge to be mounted to headshell with just two screws – no nuts required
• Compatible with any AT-VMN95 replacement stylus

Specifications

• Frequency response: 20 – 25,000Hz
• Channel separation: 23dB at 1kHz
• Vertical tracking force: 1.8 – 2.2g (2.0g standard)
• Stylus construction: Nude square shank
• Recommended load impedance: 47,000 ohms
• Output: 3.5mV (1kHz, 5cm/sec)
• Channel balance: 1.5dB (1kHz)
• Stylus shape: 2.7 x 0.26 mil Shibata
• Cantilever: Aluminum pipe
• Mount: Half-inch
• Replacement stylus: AT-VMN95SH
• Coil impedance: 3.3k ohms (1kHz)
• DC resistance: 485 ohms
• Load capacitance: 100 to 200pF
• Coil inductance: 55o mH (1kHz)
• Vertical tracking angle: 23°
• Dimensions (H x W x D): 0.68″ x 0.74″ x 1.2″
• Weight: 0.22 ounces

What’s In The Box

• AT-VM95SH Dual Moving Magnet Cartridge
